扭剪扳手主要是初緊螺栓的,它的使用很簡單,就是對準螺栓扳動電源開關就行。電動扭剪扳手主要是終緊扭剪型高強螺栓的,它的使用就是對準螺栓扳動電源開關,直到把扭剪型高強螺栓的梅花頭打斷為止。電動定扭矩扳手既可初緊又可終緊,它的使用是先調節扭矩,再緊固螺栓。電動轉角扳手主要也屬于定扭矩扳手的一種,它的使用是先調節旋轉度數,再緊固螺栓。電動角向扳手是一種專門緊固鋼架夾角部位螺栓的電動扳手,它的使用和電動扭剪扳手原理一樣
The twist-shear wrench is mainly used to tighten the initial bolt. Its use is very simple, that is, to turn the power switch on the alignment bolt. Electric twist shear wrench is mainly used for the final tightening of high strength twist shear bolts. Its use is to pull the power switch on the alignment bolts until the plum blossom head of the high strength twist shear bolts is interrupted. The electric fixed torque wrench can be tightened both initially and eventually. Its use is to adjust the torque first and then tighten the bolt. Electric angle wrench is also a kind of fixed torque wrench. Its use is to adjust the rotation degree first, and then tighten the bolt. Electric angular wrench is an electric wrench specially designed to fasten the bolts in the angle part of the steel frame. Its use is the same as that of electric torsion shear wrench.
扭剪扳手主要是終緊扭剪型高強螺栓的，它的目的就是把扭剪型高強螺栓的梅花頭打斷即可。工作時將扳手頭對準螺栓頭，扣動開關即可開始工作，幾秒后，螺栓梅花頭將被扭斷，然后抽出扳手扣動扳機將梅花頭彈出，即結束工作。
The twist-shear wrench is mainly used to tighten the twist-shear type high-strength bolt. Its purpose is to break the plum blossom head of the twist-shear type high-strength bolt. When working, the wrench head is aligned with the bolt head, and the switch can start to work. After a few seconds, the bolt plum head will be twisted off, and then pull out the wrench to pull the trigger and pop the plum head out, that is to say, the work will be finished.
濟南萬中電動扳手有限公司致力于電動扭矩扳手，扭剪扳手家服務，堅持“以客戶為中心”的理念，堅持“領域”，積極為客戶創造價值。
Jinan Wanzhong Electric Spanner Co., Ltd. devotes itself to the service of electric torque wrench and twist-shear wrench maker, adheres to the concept of "customer-centered", adheres to the "professional field" and actively creates value for customers.
扭剪扳手是一種終緊扭剪型高強度螺栓的工具，一般有電動扭剪扳手和手動扭剪扳手，其中電動扭剪扳手比較常見。
Twist shear wrench is a tool for ultimate tightening and high strength bolts. There are generally electric and manual twist shear wrenches, among which electric twist shear wrenches are more common.
電動扭矩扳手的特點：（1）使用壽命長（2）手柄和機殼材料散熱性好（3）功率大（4）耐撞擊性強（5）手使用性價比比較高
The characteristics of electric torque wrench are: (1) long service life (2) good heat dissipation of handle and shell materials (3) high power (4) strong impact resistance (5) the highest cost performance of hand use.
常用扭剪扳手螺栓規格：M16*50、16*55、16*60、16*65、16*70、16*75、16*80、20*50、20*55、20*60、20*65、20*70、20*75、20*80、22*50、22*55、22*60、22*65、22*70、22*75、22*80、24*60、24*65、24*70、24*75、24*80、24*85、24*90
Specifications of commonly used twist-shear wrench bolts: M16*50, 16*55, 16*60, 16*65, 16*70, 16*75, 16*80, 20*50, 20*60, 20*65, 20*70, 20*75, 20*80, 22*50, 22*55, 22*60, 22*65, 22*65, 22*65, 22*70, 22*70, 22*75, 22*80, 24*60, 24*65, 24*70, 24*75, 24*80, 24*85, 24*90
扭剪扳手的應用： 扭剪型高強螺栓的初緊可使用沖擊電動扳手或定扭矩扳手,而終緊必須使用扭剪扳手，所以扭剪扳手是專門終緊扭剪型高強螺栓的。扭剪扳手的使用： 扭剪扳手主要是終緊扭剪型高強螺栓的，它的目的就是把扭剪型高強螺栓的梅花頭打斷即可。工作時將扳手頭對準螺栓頭，扣動開關即可開始工作，幾秒后，螺栓梅花頭將被扭斷，然后抽出扳手扣動扳機將梅花頭彈出，即結束工作。
Application of Torsion-shear wrench: The initial tightening of Torsion-shear high-strength bolt can use impact electric wrench or fixed-torque wrench, and the final tightening must use Torsion-shear wrench, so the Torsion-shear wrench is specially designed for the final tightening of Torsion-shear high-strength bolt. Use of torsion shear wrench: The main purpose of torsion shear wrench is to break the plum blossom head of torsion shear high strength bolt. When working, the wrench head is aligned with the bolt head, and the switch can start to work. After a few seconds, the bolt plum head will be twisted off, and then pull out the wrench to pull the trigger and pop the plum head out, that is to say, the work will be finished.
扭剪扳手的特點： 操作方便、省時省力、方便
The characteristics of torsion shear wrench: easy to operate, time-saving, labor-saving, safe and convenient
另外說明扭鉅和扭剪電動扳手是不能通用的
It also shows that the electric wrench with large torsion and shear can not be used.
